Turbo Lux 2 Flow Meter

Turbo Lux 2 Flow Meter

  • VdS Logo mid grey 600.jpg
Size Range DN80 (3") to DN250 (10")
Maximum Working Pressure 16bar (232psi)
Measuring Range From 420 L/min to 18.000 L/min (depending on size)
Temperature Range 4ºC to 50ºC (39ºF to 122ºF)
Approvals VdS

The Turbo-Lux 2 orifice flow meter is used to measure the flow of clear liquids in closed pipelines. The installation position and direction of flow are flexible. The areas of application focus on measuring flow quantities in stationary water-based extinguishing systems for use in water supply test pipes. The Turbo Lux 2 is VdS Approved.

The orifice plate flowmeter Turbo-Lux 2 consists of a Differential Pressure Transmitter for installation on the pipe (between flanges) and a portable Bypass Meter. The Bypass Meter contains a conical Measuring Glass Tube with a Float. The fluid flows from the pipe, through the inlet, into the measuring tube. Top edge of the Float indicates current flow of the fluid. A filter at the inlet prevents the foreign bodies from getting inside the Bypass Meter. Inlet and outlet ports of the bypass are arranged concentrically for easy attachment to the stationary transmitter.

  1. Differential pressure transmitter
  2. Bypass meter
  3. Measuring glass tube
  4. Float
  5. Bypass orifice
  6. Differential pressure sampling tube
  7. O-ring
  8. Screw cap
  9. Union nut
  10. O-ring
  11. Gasket
  12. Filter
