307 Swing Check Valve (Flanged)
| Size Range | DN50 (2") to DN300 (12") |
|---|---|
| Connections | ANSI Class 125/150 Flange PN16 RF Flange |
| Max Working Pressure | 20.7 bar (300 psi) |
| Body Material | Ductile Iron |
| Approvals | FM Approved, UL Listed |
Rapidrop Fig.307 is a rubber faced, flanged swing type check valve that allows water flow in one direction only. A hinged clapper remains open with water flowing in one direction, and automatically closes, with the help of an incorporated spring, when flow stops preventing backflow. Removable cover allows easy access for inspection and maintenance. Rapidrop Fig.307 check valve is suitable for installation in both horizontal and vertical position (with the flow upwards).
